Description
IPB014N06NATMA1 Infineon
Description: This is N-channel MOSFET 180 A 60 V OptiMOS 5 7-Pin D2PAK manufactured by Infineon. The manufacturer part number is IPB014N06NATMA1. While 180 a of maximum continuous drain current. The transistor is manufactured from highly durable si material. Furthermore, the product is 11.05mm wide. The product offers single transistor configuration. It has a maximum of 60 v drain source voltage. The package is a sort of d2pak (to-263). It consists of 1 elements per chip. It has a maximum operating temperature of +175 °c. With a typical gate charge at Vgs includes 106 nc @ 10 v. The product is available in [Cannel Type] channel. Its accurate length is 10.31mm. It contains 7 pins. The product carries enhancement channel mode. The product is available in surface mount configuration. Provides up to 214 w maximum power dissipation. The product optimos 5, is a highly preferred choice for users. It features a maximum gate source voltage of -20 v, +20 v. In addition, the height is 4.57mm. Whereas, the minimum operating temperature of the product is -55 °c. Its forward diode voltage is 1.2v . It provides up to 2.1 mω maximum drain source resistance.
Weight: 0.1kg
SKU: IPB014N06NATMA1
Delivery: We ship via global express services, such as DHL, Fedex, Swiss Post.
Warranty: 3 Years AW warranty, for peace of mind.
